Ultra-Containment Berm® - Economy PE Model
Manufacturer: UltraTech
Part Number: See Table Below
Description: Get the best spill containment with this lightweight and economical L-bracket berm!
• Maximum Durability: Uses a reinforced polyethylene (RPE) 30-mil liner.
• Quick Deployment: Frameless design for fast setup inside or outside.
• Easy Identification: Two-color (black/yellow) material makes tears and punctures visible.
Available in various sizes, including custom ones, it's perfect for temporary or long-term storage and spill containment from single IBCs to large frac tanks.
Features:
- L-shaped wire brackets provide sturdy sidewall support.
- 12” sidewall contains spills in drilling and fracking locations.
- Two-color (black/yellow) material makes tears and punctures easier to identify - simply look for the opposite color.
- No frames, components or excess material outside of sidewalls — excellent for use as spill containment area inside of storage sheds and other buildings or structures where floor space is a premium.
- Economical spill containment for frac tanks and other large containers.
- Custom sizes available.
Specifications:
| Part No. | Dimensions ft. (m) | Containment Capacity gal. (L) | Weight lbs.(kg) |
| 2858 | 4 x 4 x 1 (1.2 x 1.2 x 0.3) | 119 (450.46) | 8 (3.63) |
| 2859 | 6 x 4 x 1 (1.8 x 1.2 x 0.3) | 179 (677.59) | 10 (4.54) |
| 2860 | 8 x 6 x 1 (2.4 x 1.8 x 0.3) | 359 (1359) | 13 (5.9) |
| 2861 | 8 x 8 x 1 (2.4 x 2.4 x 0.3) | 478 (1809.43) | 17 (7.71) |
| 2862 | 20 x 10 x 1 (6.1 x 3 x 0.3) | 1496 (5663) | 50 (22.68) |
| 2863 | 30 x 10 x 1 (9.1 x 3 x 0.3) | 2244 (8494.46) | 53 (24.04) |
| 2864 | 40 x 10 x 1 (12.2 x 3 x 0.3) | 2992 (11326) | 67 (30.39) |
| 2865 | 20 x 12 x 1 (6.1 x 3.7 x 0.3) | 1795 (6794.81) | 43 (19.50) |
| 2866 | 30 x 12 x 1 (9.1 x 3.7 x 0.3) | 2692 (10190.33) | 59 (26.76) |
| 2867 | 40 x 12 x 1 (12.2 x 3.7 x 0.3) | 3590 (13589.63) | 74 (33.57) |
| 2868 | 60 x 12 x 1 (18.3 x 3.7 x 0.3) | 5385 (20384.44) | 105 (47.63) |
| 2869 | 50 x 15 x 1 (15.2 x 4.6 x 0.3) | 5610 (21236.16) | 132 (59.87) |
| 2870 | 60 x 15 x 1 (18.3 x 4.6 x 0.3) | 6732 (25483.39) | 151 (68.49) |
| 8240 | 6 x 6 x 1 (1.8 x 1.8 x 0.3) | 269 (1018.28) | 9.0 (4.1) |
| 8241 | 10 x 10 x 1 (3 x 3 x 0.3) | 748 (2831.49) | 23.0 (10.4) |
| 8242 | 12 x 12 x 1 (3.7 x 3.7 x 0.3) | 1077 (4076.88) | 29.0 (13.2) |
| 8243 | 25 x 12 x 1 (7.6 x 3.7 x 0.3) | 2244 (8494.464) | 49.0 (22.2) |
| 8244 | 50 x 10 x 1 (15.2 x 3 x 0.3) | 3740 (14157.44) | 84.0 (38.1) |
| 8245 | 50 x 12 x 1 (15.2 x 3.7 x 0.3) | 4488 (16989) | 88.0 (40.0) |
You will be contacted with a freight quote for shipping
This Ultra-Containment Berm is great for anyone who needs to contain spills, like those in the drilling and fracking industries, or for storage facilities. It can be used both temporarily and for long - term storage. You can use it to contain spills from a single IBC or large frac tanks. It comes in a wide range of sizes, with dimensions from 4x4x1 ft to 60x15x1 ft, and weights from 8 lbs to 151 lbs. This makes it suitable for different spaces and needs. Whether you have a small shed or a large industrial area, there's a size for you, and custom sizes are also available.
